black UHMW lining/ truck bed sheets factory/ dump truck liners 15mm, Uhmw extrusion pump uhmw- pe lining Extrusion uhmw
| ≥500Kilograms | US $3.00-$9.00 |
Basic Info
Product Description
black UHMW lining/ truck bed sheets factory/ dump truck liners 15mm, Uhmw extrusion pump uhmw- pe lining Extrusion uhmw pump
Why Choose Us
l More than 15 years' professional manufacturing experience with own factory.
l Virgin 100% material produced, high quality with good surface and color make ensured
l GB/T 19001-2008 ; ISO 9001:2008 certification.
l Competitive price, In stock, Fast delivery, and Excellent service.
l OEM available. Special character is available :According to different requirements with different application, color, size, shape and special specifications can be customized, such as anti-UV, anti-static and so on.
The properties of UHMW-PE chute bin liner:
Property | Unit | Value |
Density | g/cm3 | 0.93-0.96 |
Average molecular weight | g/mol | 3million- 10 million |
Tensile strength (23°C in air) | MPa | 22 |
Breaking strength | MPa | 42 |
Tensile strain at break | % | 600 |
Charpy impact strength (notched) | mJ/mm2 | No break |
Ball indentation hardness | N/mm2 | 42 |
Shore D hardness | -- | 65-70 |
Abrasion | % | 70-80, steel = 100 |
Static Friction Coefficient | -- |
≤0.16 |
Kinetic Friction Coefficient | -- |
≤0.10 |
Water Absorption | -- | NIL |
Elongation at break at 23 degress | % | ≥300 |
Temperature resistance | °C | -269 to +85 |
Melt Temperature | °C | 130-140 |
Our UHMW-PE liner Characters:
1.very flat on the surface
2.The thickness tolerance is +2 -0,some made according to your requirements.
3.The color is pure and any color can be made by us.
4.We can give you an accurate size of UHMW-PE Sheet with advanced machine.
5.Different shaped UHMW-PE Sheets also can be made by us like bending sheet.
6.According to different requirements with different application, special specifications can be customized, like anti-UV, fire-resistant,anti-static and with other characters.
Xingxing Products Range
UHMWPE sheet,UHMWPE board,UHMWPE panel,UHMWPE plate,UHMWPE rod,Extruded UHMWPE rod,UHMWPE bunker liner,UHMWPE coal bin liner,UHMEPE hopper liner,UHMWPE tipper liner,UHMWPE chute liner,UHMWPE silo liner,UHMWPE truck bed liner,UHMWPE screw conveyor liner,UHMWPE park lot wheel stop,UHMWPE guide track,wear strips.UHMWPE filter plate,UHMWPE marine fender facing pad,UHMWPE parts,UHMWPE pad,UHMWPE dock bumper,UHMWPE suction box covers,UHMWPE outrigger pads
Extruded HDPE sheet,HDPE sheet,HDPE bar,HDPE track mats,HDPE parts,HDPE rod.
PP sheet,PVC sheet and Other Engineering Plastic Products.
Our UHMW-PE liner standard sizes:
1.Thickness: 6 - 300mm
2. Width: max 2000mm
3. Normal standard size:
Length(mm) | Width(mm) | Thickness(mm) |
2000 | 1000 | 6-300 |
3000 | 1500 | 6-300 |
4700 | 1200 | 6-300 |
5000 | 1300 | 6-300 |
4500 | 2000 | 6-300 |
3050 | 1220 | 6-100 |
Any small size need us to cut , we can satisfy your special need .
FAQ
Customer Questions 1 : We have a strict control on our quality so we must assure the uhmwpe parts that we imported have good quality ,how can you assure that ?
XINXING :Dear sir ,that is really a good question .We control our quality from raw material to the processing process in every aspects .Also we use TICONA brand material as the raw material .Their quality is very famous all over the world .
Customer Questions 2: Can you exported by yourself and which country that you have exported ?
XINXING :Dear Sir ,we have exported license and we have exported to many countries like America ,Russia ,Africa ,Thailand ,Malaysia ,Indonesia ,Japan ,Germany ,Poland ,Uk ,Canada and many other countries .
Customer Questions 3:If we purchase from you ,what benefits that you can bring to us ?
XINXING : We can bring you benefits in four aspects : Price ,Service ,Delivery time ,Quality
Price :If you buy from us ,we can assure that your price is competitive than others since we are the largest manufacture for UHMWPE products
Service :We have special sales and single service for you which will make sure that you can get every good service on each order
Delivery time :We have nearly 16 sets pressing machines and 7 sets CNC machine to do the processing which will make sure a very fast delivery time
Quality : Quality is the best since raw material and our pressing machine is best
Customer Questions 4: We are very urgent on this sample order and quantity is only 4 tons ,could you finished them in 10 days ?
XINXING :OK ,even our normal delivery time is 15 days ,but we would like to help you solve this problem .
Packaging : pallet packing or as client need.
XINXING can provide various UHMWPE & HDPE products with the good quality at reasonable price according to your requirement.
Any questions, please feel free to contact us.
Many thanks for you visit us !
