White HDPE Cable support Block /HDPE Pipe support block /HDPE block
| ≥20Pieces | US $3.00-$9.00 |
Basic Info
Product Description
A.HDPE as pipe support have the following advantages:
1. HDPE exhibits virtually no water absorption
2, Non-Toxic
3. Low coefficient of friction
4. Corrosion resistant
5. Abrasion and impact resistant
6. Wear Resistant
7. Dielectric
8. Weatherproof
B.Chacters of HDPE as pipe support
Property | ASTM Test | Units Metric (US) | Typical Values |
Specific Gravity | D792 | gm/cm° | 0.926-0.934 |
Tensile Strength @ Yield | D638 | MPa (PSI) | 21 (3100) |
Tensile Strength @ Break | D638 | MPa (PSI) | 48 (7000) |
Elongation @ Break | D638 | % | 350 |
Young's ("E") Modulus (23°C) | D638 | MPa (PSI 105) | 690 (1.0) |
Young's ("E") Modulus (-269°C) | D638 | MPa (PSI 105) | 2970 (4.3) |
Izod Impact Strength (23°C) | D256(1) | J/m (ft-LBS/in notch) | 140 (30) |
Izod Impact Strength (-40°C) | D256(1) | J/m (ft-LBS/in notch) | 100 (21) |
Hardness, Shore "D" | D2240 | - | 62-66 |
Abrasion Resistance | (2) | - | 100 |
Water Absorption | D570 | % | Nil |
Relative Solution Viscosity | D4020 | dl/gm | 2.3-3.5 |
Density |
| (lbs./cubic in.) | .034 |
C HDPE Application Areas
1. Textile Industry:
2. Chemical Industry:
3. Food Processing Industry:
4. Paper Industry:
5. Material Handling:
6. Farm Implement
7. Mining & Metals Processing Industries:
8. Transportation:
9. Consumer Products:
10. Waste Water Treatment:
UHMWPE Material can endure a high pressure .No matter what big or heavy of the pipe ,the UHMWPE can works very well on all pipes .
