Multi-Bar Wark Knitting Machine with Thread Presser (GE2EF40/20)
| ≥1Piece | Negotiable |
Basic Info
Product Description
Multi-bar Wark Knitting Machine with Thread PresserMain Usage for Wark Knitting Machine
The warp knitting machine specializes in producing netted jacquard, such as netted curtain, netted table cloth, elastic and un-elastic netted dlothing and lace. The combination of multi-bars, and thread presser increase the jacquard ability and effect of the warp knitting machine.
Recently, along with the development and application of various new fiber, perfecting the function of modem multi-bar warp-knitting machine with thread presser, and reforming the warp-knitted technique and new dyeing technique, the multi-bar warp-knitted fabric with thread presser has further improvement in function, external appearance and quality etc.
And it is widely used for all kinds of colthing and household products.
Won the national invention patent Patent No. ZL200610173400.8
The patent for utility model Patent No. ZL200720036919.1
The patent for utility model Patent No. ZL200720036918.7
The patent for utility model Patent No. ZL200720036917.2
The patent for utility model Patent No. ZL200720036916.8
The patent for utility model Patent No. ZL200720036914.9
The patent for utility model Patent No. ZL200720036915.
| Needle type | groove needle |
| Gauge | E18 E24 |
| Nominal width | 132" |
| Diameter of the beams | 21" |
| Guide bars | 40 |
| bars before thread presser | 20 |
| bars after thread presser | 16(18) |
| Ground bars let-off mechanism | Electronically multi-speeds |
| Drawing mechanism | Electronically draw |
| Winding units | adjustable and identical tensioning winding mechanism |
| Main shaft rotate speed | 280-300r/min |
| The shogging mechanidm | Ground comb E,pattern comb EH |
| Pattern comb let-off device | Passive let-off |
